Tech Specs
PRODUCT DESCRIPTION & EXTERNAL SPECS
● Dual-Channel Active Instrument Preamp & Re-Amp Device
● Independent Instrument Preamp And Re-Amp Signal Paths
● CineMag Transformer Isolation On Each Signal Path
● Connect Instrument, Line-Level, & Speaker-Level Signals
● Compatible With Passive And Active Instruments, Keyboards, And Pedals
● Speaker Input With Direct Through Or Built-In Power Soak For Silent Operation
● Stepless Re-Amp Output Level Control For Attenuation Or Gain
● Balanced Line-Level I/O On XLR And 1/4" Connections (No Phantom Power Required)
COMPONENTS & INTERNAL SPECS
● Custom CineMag USA Transformers On Each Signal Path (Inputs & Outputs)
● Switchable JFET Discrete Or JFET Op-Amp Instrument Input Stage
● Fully Active Circuitry With Ultra-Low-Noise Design
● High-Quality Components Throughout Signal Path
● Internal Universal AC Power Supply
PERFORMANCE SPECS
● Channels: 2
● Maximum Instrument Input Level: +18 dBu (6 VRMS)
● Instrument Input Impedance: Variable 120kΩ To 1MΩ
● Re-Amp Output Level: Stepless Attenuation To Gain
● Speaker Power Soak: 8 Ohms, 50 Watts Max
● Balanced Line Output: True Line Level On XLR And 1/4"
● Phase-Invert & Ground/Lift Per Channel
● Power: 90–240V AC, 50–60 Hz
Popular Uses
● Run DAW tracks back through any tube amp or effects pedals
● Cleanly mix/match any guitar and studio sources with or without analog vibe using the JFET /
Op-Amp switch
● Use the built-in power soak to record tube amps up to 50W (8Ω impedance) without engaging
the speaker for silent tracking.
● Easily add delays, reverbs, tremolos, or ring modulators to vocal chains, drum busses, and
much more.
● Run your guitar signal through studio-grade preamps, compressors, EQs & more to get the full
impact of a pro studio signal chain on guitar recordings
